We specialise in the research, develpomeng and production of resinoid, vitrified and electroplated diamond & CBN wheels. These products are used in the fields of tools, mould & die, bearing, Compressor, Automobile, Aerospace, Ceramic and Magnetic materials and IT.
Face Grind Akemat & UT. MA
FACE GRINDING WHEELS FOR AKEMAT AND UT. MA EQUIPMENT
D4A2 150mm x 3/8 x 32mm D 240 R 125 B 1/16 W=1/8
B12V9 200mm x 1/2 x 32mm CBN 220 R 100 B 1/16 S=20°
FACE GRINDING WHEELS FOR AKEMAT AND UT. MA EQUIPMENT
D4V2 6 x 13/32 x 32mm D 320 R 100 B 3/32 W=1/8
B4V2 200mm x 13mm x 32mm CBN 180 R 100 B 2mm W=4mm
Top Grind Akemat & UT. MA
TOP GRINDING WHEELS FOR AKEMAT AND UT. MA EQUIPMENT
D14B1 125mm x 8mm x 32mm D 180/400 R 100 B 1/4 U=5mm
D3M1 125mm x 8mm x 32mm D 220/600 R 125/100 B 3/8 U=4mm
Side Grind Akemat & UT. MA
SIDE GRINDING WHEELS FOR AKEMAT AND UT. MA EQUIPMENT
D4A1 3 x 9/16 x 20mm D 220 R 75 B 3/16 U=5/32
B4A1 100mm x 9/16 x 20mm CBN 120 R 50 B 5/32 U=5/32
Face Grind Vollmer
FACE GRINDING WHEELS FOR VOLLMER EQUIPMENT
D4A2 115mm x 11mm x 32mm D 280 R 100 B 1/8 W=1/8
B4A2 125mm x 3/8 x 32mm CBN 180 R 75 B 1/16 W=1/8
D4V2 125mm x 11mm x 32mm D 280 R 100 B 2mm W=4mm
B4V2 125mm x 13mm x 32mm CBN 180 R 75 B 2mm W=4mm
D12V9 125mm x 12mm x 32mm D 240 R 100 B 1/16 S=20°
B12V9 120mm x 12mm x 32mm CBN 180 R 100 B 1/4 S=30°
Top Grind Vollmer
TOP GRINDING WHEELS FOR VOLLMER EQUIPMENT
D6A2 125mm x 18mm x 32mm D 180 R 100 B 1/4 W=3/16
B6A9 115mm x 18mm x 32mm CBN 150 R 75 B 1/8 U=1/4
D6A2 125mm x 21mm x 32mm D 180/400 R 100/75 B 3/8 W=5mm
B6A2 115mm x 18mm x 32mm CBN 120/220 R 100 B 1/4 W=5mm
Side Grind Vollmer
SIDE GRINDING WHEELS FOR VOLLMER EQUIPMENT
D4A1 3 x 10mm x 32mm D 220 R 75 B 3/16 U=5/32
B4A1 100mm x 10mm x 32mm CBN 120 R 50 B 5/32 U=5/32
